What is the working principle of a solid flow meter?
Solid flow meter - suitable for measuring solid mass flow in metal enclosed pipelines with a wide range from kg/h to t/h. This system is suitable for online monitoring of solid flow rates such as powder, dust, small balls, and granules in pneumatic conveying or free falling bird hopper bodies (1nm-20mm). Solid flow meter, solid flow meter, microwave flow meter, microwave solid flow detector, microwave solid flow measuring instrument. The measurement principle of solid flow meter is based on the physical principle of Doppler effect. The sensor generates a microwave field inside the pipeline, and the microwave is reflected by the particles flowing inside the pipeline. The changes in frequency and amplitude can accurately measure the solid flow rate. Non flowing particles such as dust deposits will not be included in the calculation. The installation of EDIT and SWR is very simple and cost-effective. It involves welding a base onto the pipeline and threading the solid flow meter sensor into the base. The sensor is connected to a transmitter mounted on a DIN rail through a cable, and the transmitter outputs a 4-20mA measurement result signal, RS232
2, and RS485 interface. Calibration is very easy and can be completed through MF-SMART intelligent software. Weld a base onto the pipeline. Drill an 18mm hole in the pipeline and insert the sensor flush with the inner diameter of the pipe. For debugging and calibration, we need a laptop with the MF-SMART software we provide. The serial COM interface in front of the transmitter can be connected to a laptop, while the RS485 interface can be used to connect to a PLC system. Calibration can be performed through one
2. Application status and development trend of flow meters
Application status and development trend of flow meters As the core equipment in the field of industrial measurement and metrology, flow meters have applications covering multiple industries such as energy, environmental protection, chemical industry, and transportation.
. With breakthroughs in microelectronics technology, new materials, and intelligent technology, Jingyu flow meters are evolving from traditional mechanical methods to high-precision, intelligent, and modular directions. The following analysis will focus on the current application status, technology classification, market landscape, and future trends.1. Application Status Industry Demand Driven Growth Global industrial output improvement and energy structure transformation drive the continuous expansion of flowmeter demand.
. In 2020, the production of flow meters in China reached 71.9153 million units, with a market demand of 74.6659 million units and a market size exceeding 9.987 billion yuan. Among them, the petrochemical industry has the highest proportion (64.63%), while urban gas (9.
