Isco 2150 Flow Meter Troubleshooting: Resolving Data Logger Memory Faults and Sensor Signal Drops in Wastewater
Quick Answer
For an Isco 2150 flow meter that shows a memory fault or drops sensor signal at a wastewater site, check the 12 V DC supply, the logger ground connection, and the sensor cable first. Most memory errors come from low voltage, a full SD card, or a dead internal battery. Most signal drops come from moisture in the connector, a floating shield, or a damaged Doppler or ultrasonic level sensor cable.
This guide is for plant electricians, integrators, and maintenance engineers who manage open channel flow metering in wastewater networks. We have seen these faults on customer sites in Queensland, Vietnam, Mexico, and Saudi Arabia. The fixes below cover field inspection and permanent replacement decisions.
What a Memory Fault on the Isco 2150 Actually Means
Here is the thing. A memory fault on the Isco 2150 is almost never the main board on the first visit. The logger stores velocity and level data plus site settings in nonvolatile memory. A MEM ERROR or LOG FULL message means the processor cannot verify a write cycle.
Check the input voltage at the logger terminal block with a digital multimeter. A healthy 12 V DC battery reads between 12.4 and 13.8 V. A solar regulator under load can dip to 11.8 V at night. If the voltage falls below 11.5 V during a logger write, the Isco 2150 can report a memory fault even though the board is fine.
Open the logger enclosure and inspect the internal coin cell. Because a dead coin cell stops the real time clock and can corrupt the data header, replace it if the voltage is below 2.8 V. The logger may still read flow but it cannot time stamp records correctly.
Power and Ground Checks That Solve Most Cases
Most wastewater sites use AC mains, solar, or a telemetry cabinet. The Isco 2150 often shares a 12 V DC supply with a modem or sampler. Shared supplies cause dips. Move the logger supply to its own fused circuit with 1.5 mm2 or larger cable for runs over 20 m.
Ground the logger to a clean earth bus. Do not bond the DC negative to a pump contactor rail. In a sewage pump station, a motor start can pull the DC common hard enough to create a memory write fault. We have seen this at a pump station in Ho Chi Minh City that ran two 7.5 kW pumps on the same panel.
Use a shielded cable for the level sensor and velocity sensor. Connect the shield drain only at the logger end. Leave the sensor end floating. This prevents a ground loop between the sensor body and the logger. If the signal drops only when a pump starts, a loose shield termination is the usual cause.
Sensor Signal Drops on Ultrasonic and Doppler Sensors
The Isco 2150 accepts an ultrasonic level sensor and a Doppler velocity sensor. In wastewater, signal drops are more common on the Doppler sensor because it sits in the flow stream. Inspect the cable for cuts, crushed sections, and cable tie damage. A cable that rubs against a concrete channel wall will eventually short the signal.
Moisture inside the sensor connector is another common cause. Open the connector, clean the pins with contact cleaner, and replace the desiccant pack. In Southeast Asia and Gulf Coast plants, replace desiccant every 3 months. Humidity enters through the breather hole and condenses inside the logger box.
If the ultrasonic sensor drops signal only during heavy rain, check for foam. Foam absorbs the acoustic pulse. Increase the blanking distance by 0.1 to 0.3 m and make sure the sensor is mounted above the maximum water surface. Do not aim the ultrasonic sensor at a side wall or a stainless steel ladder rung.
SD Card and Data Offload Faults
Some Isco 2150 loggers use an SD card for extra storage. If the SD card is full, the logger may show LOG FULL instead of writing new records. Use a FAT32 formatted industrial SD card wit
Back up the data before formatting. Connect a laptop through the RS232 or USB service port. Open the Flowlink or Signature software and read the current site profile. Save the profile file to the laptop. Clear the logger memory, reload the site profile, and run a bench test at 0.00 m level. The display should return a stable 4 mA signal from the level sensor.
Firmware and Site Profile Reset
A corrupted site profile can look like a hardware fault. If the Isco 2150 display shows a reading that jumps from 0.00 to a negative level, reload the site profile first. This is especially true after a lightning storm or a power outage longer than 24 hours.
For a hard reset, remove power, remove the coin cell, and wait 5 minutes. Reinstall the coin cell, power the logger, and upload the saved site profile. This clears most software related memory faults without replacing the main board.
Do not run the logger with an empty site profile. An empty profile can drive the analog output to a fault state and confuse the SCADA display. Load the correct channel shape, level sensor type, and velocity sensor type before returning the unit to service.
When to Replace the Logger or Sensor
Replace the Isco 2150 main board if the memory fault returns after a stable 12 V supply, a new coin cell, a formatted SD card, and a clean profile reload. A board-level flash failure is not field repairable. Look for burnt components near the power input or a swollen capacitor.
Replace the sensor cable or sensor head if the signal drop repeats with a known good logger. Connect a 4-20 mA loop simulator and watch the logger input. If the logger tracks the simulator but not the field sensor, the problem is the sensor cable or sensor transducer.
Silver Instruments Spare Parts and Alternatives
Silver Automation Instruments supplies flow meters and process instruments for wastewater plants across Southeast Asia, Australia, Latin America, the Middle East, and Africa. If the Isco 2150 logger board is no longer economical to repair, we can propose an electromagnetic flow meter for a pressure pipe or an ultrasonic open channel flow meter for a flume or weir.
Send us your pipe size (DN), flow range, pressure (bar), temperature (°C), and the type of channel or flume. We will reply with a quote and a technical comparison. For a wastewater treatment plant, we normally recommend a corrosion resistant electromagnetic flow meter for DN15 to DN600 pipes and a non-contact ultrasonic flow meter for open channels.
Contact Silver Automation Instruments. Tel: +86-135-1213-1526. WhatsApp: 86-135-12131526. WeChat: +86 13512131526.
FAQ
Why does the Isco 2150 show LOG FULL even after operators delete files?
Format the SD card or clear the logger memory through the Flowlink software. Deleting files from a laptop does not always remove the logger index file.
Can a low battery cause a sensor signal drop?
Yes. At low DC voltage, the logger input circuit can rail and the level reading can drop to zero. Check voltage under load, not with the charger disconnected.
How do I stop a Doppler sensor cable from failing in a channel?
Run the cable inside flexible conduit and anchor it every 0.5 m. Keep the cable out of the flow stream and away from rags and grit.
Should I connect the sensor cable shield at both ends?
No. Connect the shield at the logger end only. Connecting both ends creates a ground loop that can make the sensor signal drop at motor start.
What is a realistic replacement if the Isco 2150 cannot be repaired?
For open channels, an ultrasonic flow meter with a 4-20 mA output works well. For full pipes, an electromagnetic flow meter is more accurate. Silver Instruments can supply both with the correct output for your SCADA or RTU.
