Honsberg Flow Meter Catalog: Heavy-Duty Paddlewheel, Piston, and Gear Sensors for Machinery OEMs
Quick Answer: Silver Automation Instruments supplies heavy-duty paddlewheel, piston, and gear flow sensors that match Honsberg catalog specifications for machinery OEMs. The typical OEM skid range is 0.05 l/min to 250 l/min, with pressure up to 200 bar and temperature from -20 °C to 120 °C. Send your flow range, viscosity, pressure, and connection size for a model and price within 24 hours.
What This Catalog Covers for OEM Machine Builders
Many machine builders do not need a full inline flow meter with a digital display. They need a compact sensor that sends a frequency or 4-20 mA signal to a PLC. Honsberg type sensors cover this job. The Honsberg flow meter catalog includes heavy-duty paddlewheel sensors, piston sensors, and gear sensors. Each type suits a different fluid and flow range.
Silver Instruments keeps stock for common model ranges in Nanjing and ships to Southeast Asia, Australia, Latin America, the Middle East, and Africa. We have worked with hydraulic power unit builders, lubrication skid manufacturers, and packaging machine OEMs. In practice, most engineers skip the heavy catalog reading and send us the application data instead.
Paddlewheel Sensors for Water and Coolant Loops
Paddlewheel sensors work well in clean water, cooling water, and water glycol circuits. The heavy-duty bodies are often brass or stainless steel. Typical Honsberg model families like VHS and VHZ handle flows from 0.5 l/min to 200 l/min depending on pipe size. The sensor gives a pulse output. You wire it directly to a PLC input or a panel meter.
Here is the thing. Paddlewheel sensors are cost-effective but they need straight pipe runs. Most OEM cooling skids have tight space. Because of this we often recommend a compact insertion paddlewheel with a short tee. A plastic injection molding machine builder in Vietnam uses VHS-02 sensors on each mold cooling loop. They detect low flow before a mold overheats.
Piston Sensors for Low Flow and High Viscosity
Piston sensors suit viscous fluids like gear oil, hydraulic oil, and lube oil. They are positive displacement sensors. They read low flows with good repeatability. A Honsberg type piston sensor can measure 0.05 l/min up to 10 l/min at viscosities from 5 cP to 500 cP. Brass and stainless steel bodies are common.
Industrial gearbox lubrication is a good fit. A marine gearbox service team in Singapore uses piston sensors on test benches. They check oil flow at 2 l/min at 40 cP. The pulse signal goes to a data logger. The piston sensor has only one moving part and handles cold start viscosity spikes. You do not need a high turndown electronic meter for this task.
Gear Sensors for Hydraulic Oil and Lubrication Monitoring
Gear sensors measure flow by two rotating gears. They are robust and suit hydraulic oil, diesel, and lube oil up to 200 bar. Honsberg type gear sensors like the ZHM series cover 1 l/min to 250 l/min. Outputs are pulse or 4-20 mA. They fit directly into hydraulic return lines or lube oil manifolds.
A hydraulic power unit OEM in Australia uses gear sensors on each filter outlet. They monitor return line flow to confirm the pump is not bypassing. If flow drops below a set point the PLC alarms. That alarm saves the customer from running a pump dry. We have seen this on many customer sites.
Signal Output and Connection Details That Matter
OEM buyers often ask us about signal options. Most heavy-duty Honsberg catalog sensors provide a frequency output, a 4-20 mA analog output, or both. Frequency works for PLC counters. Analog works for PLC analog inputs. Some models include a PT100 temperature option. You can combine flow and temperature in one insertion point.
Process connections vary. Typical sizes are DN8, DN15, DN20, DN25, DN40, and DN50. Thread types include G, NPT, and BSPT. Pressure ratings go from 16 bar to 200 bar depending on body material. Temperature limits for standard models are -20 °C to 120 °C. High temperature models go to 150 °C with a stainless steel body.
Silver Instruments supplies matched cable and connector sets. Matched sets reduce wiring mistakes on site. Ask for a prewired M12 connector or a DIN 43650 plug if your panels use those.
Model Pairing for Common OEM Skid Tasks
For a cooling water loop on a packaging machine, choose a VHS-02 paddlewheel sensor with DN15 brass body and pulse output. For a low flow lube oil system on a marine gearbox, choose a piston sensor with a 0.05 l/min to 2 l/min range and a 4-20 mA output. For a hydraulic return line on a power unit, choose a gear sensor rated to 200 bar with DN20 stainless steel body and frequency output.
These pairings are examples. Your exact model depends on fluid type, viscosity, particle load, and panel input. Send us the fluid name, viscosity in cP, flow range in l/min, pressure in bar, temperature in °C, and pipe size DN. We will return a model proposal and price.
Why Machinery OEMs Buy from Silver Instruments
We keep a focused stock of Honsberg type heavy-duty sensors for OEM panels. Common models ship from Nanjing within 3 to 5 working days. Bulk orders for 50 or 100 pieces get a better unit price. We also supply Coriolis mass flow meters, electromagnetic flow meters, ultrasonic flow meters, and oval gear flow meters for larger process lines.
We know OEM buyers do not have time for long technical emails. Send a short inquiry with the application data. Our team replies within 24 hours with a model, price, and delivery estimate. Contact us at Tel: +86-135-1213-1526, WhatsApp: 86-135-12131526, or WeChat: +86 13512131526.
FAQ
Question: What flow range do heavy-duty paddlewheel sensors cover?
Answer: Most Honsberg type paddlewheel sensors cover 0.5 l/min to 200 l/min. The exact range depends on pipe size and model.
Question: Can piston sensors handle high viscosity oil?
Answer: Yes. Piston sensors handle viscosities from 5 cP to 500 cP and low flows down to 0.05 l/min.
Question: What is the maximum pressure for Honsberg type gear sensors?
Answer: Heavy-duty gear sensors can work up to 200 bar. Check the body material and connection type for your exact model.
Question: Which sensor type works for dirty hydraulic oil?
Answer: Gear sensors are more tolerant of dirty oil than paddlewheel sensors. Use a strainer upstream if the oil has large particles.
Question: Does Silver Instruments keep stock for OEM orders?
Answer: Yes. Silver Automation Instruments keeps focused stock in Nanjing for common Honsberg type models and ships within 3 to 5 working days.
